Installing Elasticsearch, Fluentd, Kibana (EFK stack) with Docker-compose (and a little theory about Ingest Pipelines)

Spoiler: Github repo.

Conception

• We use the EFK stack. This means that the stack consists of three parts:

  • E for Elasticsearch

  • F for Filebeats and Fluentd

  • K for Kibana

Notice: we will not use Logstash. It is a glitchy part of the stack, and the ELK team does not suggest using it.

"How does it work?"

• Fluentd is an agent on the client host. It makes raw strings structured, fills them with host information, and then sends them directly to Elasticsearch. Fluentd creates structured logs.

• Elasticsearch stores, manages, and sometimes takes part in converting our logs from raw strings to structured logs

-Okay, you said that Elasticsearch *sometimes* converts raw strings into structured logs, right?
- Right. It works in conjunction with things called Beats. Beats is a new part of the ELK stack (or in our case, EFK) that replaced Logstash.

• Filebeat. It is an agent on the client machine that does at least three things:

  • Creates Ingest Pipeline in Elasticsearch

  • sends raw log lines populated with host information directly to Elasticsearch

  • creates dashboards in Kibana (optional)

-What is a "ingest pipeline"? What confusion! I don't get it!
-That's how Elasticsearch replaces Logstash.
0. Filebeat stores predefined pipelines for various programs such as Nginx, Apache, Mysql, etc.
1. When you configure Filebeat, it sends these pipelines to Elasticsearch and creates two things in Elasticsearch: Ingest Pipelines and Index.
2. Then you finally activate Filebeat, and it starts sending logs containing host information to Elasticsearch.
When Filebeat sends the logs, it specifies two things in the HTTP request: the Index and the Ingest Pipeline that Filebeat wants to use for a particular log line.
3. Elasticsearch gets three things: the log string, the index name, and the Ingest Pipeline name. Then
* Elasticsearch takes the log string and puts it into the Ingest Pipeline (this actually works inside the Ingest Node)
* Ingest Pipeline creates a structured log
* Elasticsearch takes the structured log from Ingest Pipeline and writes it to the index.
-Yes, it's pretty simple!

When Filebeat sends a log, it looks like this:

curl -X POST localhost:9200/my_index/_doc?pipeline=nginx_pipeline \
  -H 'Content-Type: application/json' \
  -d '{
    "message": "172.17.0.1 - - [24/Dec/2019:10:09:42 +0000] \"GET / HTTP/1.1\" 200 95 \"-\" \"Mozilla/5.0 (Macintosh; Intel Mac OS X 10_14_6) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/78.0.3904.108 Safari/537.36\" \"-\""
}'

EFK Installation

• In ./elastalert/smtp_auth_file.yaml replace name@gmail.com and password with your actual Gmail username and password

• $ chmod +x ./ssl/certs/certificates-creator.sh && chmod +x ./ssl/certs/ca-creator.sh

• Edit ./ssl/certs/certificates-creator.sh and replace STRONG_PASSWORD with really strong password

• Edit ./ssl/certs/ca-creator.sh and replace STRONG_PASSWORD with really strong password

• $ ./ssl/certs/ca-creator.sh

• $ ./ssl/certscertificates-creator.sh

• Add to ctonrab (don't forget to replace ELK_STACK to your actual path)

  • 0 1 * * * cd /ELK_STACK/ssl/certs/certificates-creator.sh && docker-compose restart

• $ docker-compose up -d

• $ docker exec -ti elasticsearch bash -c "bin/elasticsearch-setup-passwords auto --batch"

• Copy output and save it somewhere! It's extremly important!

• Copy kibana user's password from output above and edit ./kibana/config/kibana.yml

  • Put kibana to elasticsearch.username

  • Put copied password to elasticsearch.password

• $ docker-compose restart kibana

• Edit ./elastalert/elastalert.yaml and change es_password with newly generated elastic password

• Remove ELASTIC_PASSWORD env variable from ./docker-compose.yml

• $ docker-compose up -d

• $ docker-compose restart

• Go to Kibana

  • User: elastic

  • Passord: use_one_generated_above

Creating roles and users

Fluentd Role

• Go to Kibana->Management->Security->Role->Create role

• Role name: fluentd

• Elasticsearch->Cluster privilleges: monitor

• Run as Privileges: keep it empty

• Elasticsearch->Index privileges->Privileges: check all but All, delete, delete_index

• Elasticsearch->Index privileges->Indices: fluentd-* (check all indexes that connected with fluentd)

Fluentd User

• Kibana->Management->Security->User->Create user

• Username: fluentd

• Password: whatever_you_want

• Confirm password: whatever_you_want

• Full name: Fluentd Agent

• Roles: fluentd (from above)

Filebeat Role

• Go to Kibana->Management->Security->Role->Create role

• Role name: filiebeat

• Elasticsearch->Cluster privilleges: monitor, manage_pipeline, manage_ingest_pipelines, manage_ilm, manage_index_templates

• Run as Privileges: keep it empty

• Elasticsearch->Index privileges->Privileges: check all but All, delete, delete_index

• Elasticsearch->Index privileges->Indices: filebeat-* (check all indexes that connected with filebeat)

Filebeat User

• Kibana->Management->Security->User->Create user

• Username: filebeat

• Password: whatever_you_want

• Confirm password: whatever_you_want

• Full name: Filebeat Agent

• Roles: filebeat (from above)

Okay, from this point we are ready to get logs from clients.

Client's machine installation

You have to do it for every client.

Creating Kibana Space

• Open Kibana

• Create new Kibana Space from GUI

• Go to Kibana's Console and run GET /api/spaces/space

• Copy need id from spaces output

Filebeat isntallation

• Install filebeat on clinent's machine

• Copy ./ssl/certs/rootCA.crt to client's machine /etc/filebeat/ssl/rootCA.crt

• Copy ./extensions/beats/filebeat/filebeat.yml to client's machine /etc/filebeat/filebeat.yml

• Edit /etc/filebeat/filebeat.yml

• Put filebeat to output.elasticsearch.username

• Put filebeat user's password to output.elasticsearch.password

• Put id of Kibana Space you've created above in setup.kibana.space.id

• Put ["/etc/filebeat/ssl/rootCA.crt"] in setup.kibana.ssl.certificate_authorities

• Put ["/etc/filebeat/ssl/rootCA.crt"] in output.elasticsearch.ssl.certificate_authorities

• Put your actual Kibanas URL in setup.kibana.host

• Put your actual Elasticsearch's URL in output.elasticsearch.hosts

• Copy ./extensions/beats/filebeat/ingest/nginx/access/default.json to /usr/share/filebeat/module/nginx-time/access/ingest/default.json on client's machine

• $ sudo filebeat modules enable nginx-time apache mysql system

• Change your nginx log format wit this definition:

log_format  plus '$remote_addr - $remote_user [$time_local] "$request" '
                    '$status $body_bytes_sent "$http_referer" '
                    '"$http_user_agent" $request_time $upstream_response_time';
    access_log  /var/log/nginx/access.log plus;

• Go to /etc/filebeat/modules.d/

• Edit every module enabled (nginx.yml, system.yml, apache.yml, mysql.yml) and put there actual pathes to your log files on client's machine

• $ sudo filebeat setup

• $ sudo filebeat -e

Fluentd installation

• Install td-agent See difference between Fluentd and td-agent

• Copy ./ssl/certs/rootCA.crt to client's machine /etc/td-agent/ssl/rootCA.crt

• Copy ./extensions/fluentd/php.conf to /etc/td-agent/php.conf

• Edit /etc/td-agent/php.conf

• Put /etc/td-agent/ssl/rootCA.crt in ca_file

• Put fluentd in user

• Put fluentd user's password in password

• Set actual Elasticsearch URL's in host

• Specify your actual log's path in path

• $ systemctl start td-agent

Remebmer: logs should be in PSR format. You can see example in ./extensions/php-logger/index.php

---

And here is Github repo.
